ANALYSIS AND DESIGN OF FLOOR SYSTEMS

THE ULTIMATE TOOL FOR FLOOR SYSTEMS

From framing layout to detail drawing production, SAFE integrates every aspect of the engineering design process in one easy and intuitive environment. SAFE provides unmatched productivity to the engineer with its truly unique combination of power, comprehensive capabilities, and ease-of-use.

SAPFire® Analysis Engine

CSI solvers have been tried and tested by the industry for over 45 years. The SAPFire Analysis Engine can support multiple 64-bit solvers for analysis optimization and can perform both eigen analysis and Ritz analysis. Parallelization options are available to take advantage of multiple processors.

Feature Image

SAFE offers a single user interface to perform modeling, analysis, design and reporting. A new model explorer is available for quick access to objects, properties and forms.

Feature Image

Foundations, Basemats and Footings

SAFE is ideal for modeling foundations, basemats, and footings. Easily model soil supports and zero tension soil models with uplift analysis. The area assignment of soil supports is based on the subgrade modulus, and they automatically adjust whenever the mesh changes. Basemat foundation models can include pedestals, walls, columns, beams, and piles in addition to the foundation area.

Feature Image

Design Strips

Design strips are used to define how reinforcement requirements are to be calculated. SAFE can automatically define the strips for you, or you can define them yourself.

Feature Image

Post-Tensioning (P/T)

SAFE includes the ability to define post-tensioning in slabs, as banded or distributed tendons. An interactive tendon editor simplifies the task of laying out the tendon profiles. Tendon layouts can also be automated based on strip position and direction.

Feature Image

Design Codes

SAFE offers a wide range of code-based design features for reinforced concrete and PT beam, slab design and composite steel beams. View a full list of supported design codes:

Supported Design Codes

Feature Image

Deformed Geometry

Deformed geometry can be shown after running the analysis. Values are displayed instantaneously when hovering over the model. The deformed geometry can be displayed as filled or line contour plots.
